Cable plug IP67 125A 2P+E 230V

Code: DISP021253
Cable plug IP67 125A 2P+E 230V
  • To ask a question
Width 270
Height 131
Lockable No
With hinged lid No
With socket outlet No
Number of phases 1
With child-protection No
Frequency 50
Cable entry Swivel
Extension possible No
With transparent cover No
Fault current protection No
Number of poles 3
Contact less detection of the sense of rotation No
Material Plastic
IEC-amperage, A 125
For heavy conditions (according to VDE) No
Phase inverter No
Empty locations on mounting rail No
Number of height units 1
With earth leakage switch No
Degree of protection (IP) IP67
Total number of groups 1
Clock hour position, h 6
Identification colour Blue
Voltage according to EN 60309-2 230 V (50+60 Hz) blue
Width of device 270
Height of device 131
Angle of plug Straight
Connection system Screwed terminal
Color gray
Material of case Ployamide
Ingress Protection rating, IP IP67
Temperature of operation, °C -25 - +80
Product type Cable plug
Voltage 230 V
