| Surface protection | Sendzimir galvanized |
| Deflection (angle) | 45° |
| Type of rung | Perforated profile |
| Side wall perforation | Yes |
| Material quality | Steel |
| Material | Steel |
| Inner radius, mm | 600 |
| Cable ladder width, mm | 600 |
| Cable ladder height, mm | 200 |
| Change of direction | Horizontal |
| Type of side joist | Profile (open) |
| Suitable for circuit integrity | Yes |
| Product type | Accessories for ladder trays |
| Type of accessories | 45º Horizontal bend |
| Height | 200 mm |
| Side rail thickness | 1.5 mm |
| Material | Pre-galvanized |
| Width | 600 mm |
| 19 мм | 483.8 mm |
