Pre-insulated female quick-connect terminals, 0,25-1,5mm² 2,8х0,5mm.

Code: 2A04TP
Pre-insulated female quick-connect terminals, 0,25-1,5mm² 2,8х0,5mm.
Pre-insulated female quick-connect terminals, 0,25-1,5mm² 2,8х0,5mm.
Color gray
raw material Brass
Width, mm 6
Length, mm 18.5
Material Copper
Model Sleeve
Insulation Fully isolated
Colour insulation Red
Plug dimensions Flat 2.8x0.5 mm
Nominal cross section, mm² 0.25...1.5
Material insulation PVC
