No name

Code: R5SDE328C

No name

Code: R5SDE328C
Colour Grey
Width, mm 200
Height, mm 300
Depth, mm 80
RAL-number 7035
Number of doors 1
Material Steel
Impact strength IK10
Degree of protection (IP) IP55
Suitable for outdoor set-up Yes
Wall fastening possible Yes
Surface finishing Powder coating
Pole fastening Yes
Number of locks 1
Product type Terminal box
Series SDE
Material Steel, light grey, RAL7035
Height 300 mm
Width 200 mm
Depth 80 mm
Enclosure design Hinged cover
Mounting plate Optional
Door slats Not included
Cable flanges Not included
Number of cable flanges 0 pc
Enclosure thickness 1,2 mm
Door/lid thickness 1,2 mm
Gasket Polyurethane
Degree of protection IP55
IK IK10
Seismic resistance Degree 9 of MSK-64
Mechanical strength M39
Temperature range -60...+90 °С
Climate version UHL1, OM2, OM3, U3
Flammability G1
Russian Maritime Register of Shipping Yes
Russian Classification Society Yes
