| Mounting method | Surface mounted (plaster) |
| RAL-number | 7035 |
| With mounting plate | No |
| Built-in depth, mm | 120 |
| Extension possible | No |
| Material housing | Stainless steel |
| Cover model | None |
| Width, mm | 150 |
| Height, mm | 300 |
| Depth, mm | 120 |
| Degree of protection (IP) | IP66 |
| Product type | Terminal box |
| Series | SDI |
| Material | Stainless steel AISI316 |
| Height | 300 mm |
| Width | 150 mm |
| Depth | 120 mm |
| Enclosure design | Screw cover |
| Mounting plate | Optional |
| Door slats | Not included |
| Cable flanges | Not included |
| Number of cable flanges | 0 pc |
| Enclosure thickness | 1,2 mm |
| Door/lid thickness | 1,2 mm |
| Gasket | Silicon |
| Degree of protection | IP66 |
| IK | IK10 |
| Seismic resistance | Degree 9 of MSK-64 |
| Mechanical strength | M39 |
| Temperature range | -60...+90 °С |
| Climate version | UHL1, OM2, OM3, U3 |
| Flammability | NG |
| Russian Maritime Register of Shipping | Yes |
| Russian Classification Society | Yes |
