Diameter conductor, mm | 0.573 |
Nominal cross section conductor, mm² | 0.257 |
AWG-size | 23 |
Stranding element | Pairs |
Core insulation material | Polyolefin |
Core identification | Colour |
Screen over stranding element | Braiding |
Screen over stranding | Foil |
Material outer sheath | Other |
Colour outer sheath | Red |
Outer diameter approx., mm | 7.4 |
Permitted cable outer temperature during assembling/handling, °C | -5…70 |
Permitted cable outer temperature after assembling without vibration, °C | -25…70 |
Category | 7 |
Cable make-up (type) | S/FTP |
Conductor material | Copper, bare |
Flame retardant | According to IEC/EN 60332-3-22 |
NVP value, % | 78 |
Type of conductor. | Solid conductor |
Number of cores. | 8 |
Product type | Copper cable |
System category | CAT 7 |
Color | Red |
System type | shielded |
Scope of use | Plenum Rated Cable |
Cable type | S/FTP |
Standards for fire safety | FR HF |
Diameter of cable, mm | 7.4 |
