Information cable CAT 7А, S/FTP, HF, drum 500м, aqua

Code: RN7ASFA01YL
Nominal cross section conductor, mm² 0.257
Core insulation V001108 - ПОЛИОЛЕФИН
Core identification Colour
Stranding element Pairs
Colour outer sheath Yellow
Category 7A (IEC)
Diameter conductor, mm 0.573
Conductor material Cu, bare
Screen over stranding element Braiding
Screen over stranding Foil
Material outer sheath Other
Conductor category Class 1 = solid
Operating temperature, flexible, °C -5…70
Operating temperature, fix, °C -25…70
AWG-size 23
Number of cores 8
Halogen free (acc. EN 50267-2-2) Yes
Outer diameter approx., mm 7.4
Low smoke (acc. EN 61034-2) Yes
Type of conductor. Solid conductor
Conductor material. Cu
Number of cores. 8
Cable make-up (type) S/FTP (SF/UTP)
Fire protection HF
Frequency characteristic 1200 MHz
Type of mounting Indoor
