Information cable CAT 6А, U/UTP, LSLTx, drum 500м, aqua

Code: RN6AUUA03AQ
Nominal cross section conductor, mm² 0.257
Core insulation V001108 - ПОЛИОЛЕФИН
Core identification Colour
Stranding element Pairs
Colour outer sheath Other
Category 6A (IEC)
Diameter conductor, mm 0.573
Conductor material Cu, bare
Screen over stranding element None
Screen over stranding None
Material outer sheath Other
Conductor category Class 1 = solid
Operating temperature, flexible, °C -5…70
Operating temperature, fix, °C -25…70
AWG-size 23
Number of cores 8
Halogen free (acc. EN 50267-2-2) Yes
Outer diameter approx., mm 7.4
Low smoke (acc. EN 61034-2) Yes
Type of conductor. Solid conductor
Conductor material. Cu
Number of cores. 8
Cable make-up (type) U/UTP (UTP)
Fire protection LSLTx
Frequency characteristic 700 MHz
Type of mounting Indoor
