| Diameter conductor, mm | 0.58 |
| AWG-size | 23 |
| Stranding element | Pairs |
| Core insulation material | Polyolefin |
| Core identification | Colour |
| Screen over stranding element | None |
| Screen over stranding | Foil |
| Colour outer sheath | Red |
| Outer diameter approx., mm | 7.4 |
| Permitted cable outer temperature during assembling/handling, °C | -5...70 |
| Permitted cable outer temperature after assembling without vibration, °C | -25...70 |
| Category | 6A (IEC) |
| NVP value, % | 78 |
| UV resistant | No |
| Conductor material | Copper |
| Material outer sheath | Polyolefin |
| Conductor category | Class 1 = solid |
| Protective sheath | No |
| Number of cores | 8 |
| Suitable for underground installation | No |
| Conductor surface | Bare |
| Cable make-up (type) | U/FTP |
| Product type | Copper cable |
| System category | CAT 6A |
| Color | Red |
| System type | shielded |
| Scope of use | Plenum Rated Cable |
| Cable type | U/FTP |
| Standards for fire safety | FR HF |
| Diameter of cable, mm | 7.4 |
| 19 мм | ≥ 10 Ø |
