Diameter conductor, mm | 0.51 |
AWG-size | 24 |
Stranding element | Pairs |
Core insulation material | Polyolefin |
Core identification | Colour |
Screen over stranding element | None |
Screen over stranding | None |
Colour outer sheath | Red |
Outer diameter approx., mm | 5.2 |
Permitted cable outer temperature during assembling/handling, °C | -5...70 |
Permitted cable outer temperature after assembling without vibration, °C | -25...70 |
Category | 5E |
NVP value, % | 67 |
UV resistant | No |
Conductor material | Copper |
Material outer sheath | Polyolefin |
Conductor category | Class 1 = solid |
Protective sheath | No |
Number of cores | 8 |
Suitable for underground installation | No |
Conductor surface | Bare |
Cable make-up (type) | U/UTP |
Fire protection | FRHF |
Frequency characteristic, Hz | 250 MHz |
Type of mounting | Indoor |
19 мм | ≥ 10 Ø |
