Material Steel
Type of surface With powder coating
Colour Grey
Model With permanent frame
Height, mm 2200
Width, mm 600
Depth, mm 800
Demountable Yes
Degree of protection (IP) IP20
Number of doors 2
Number of height units 47
Mounting level Front and rear
Type of profile rail Crank
With roof plate Yes
With earthing Yes
With front door Yes
With backside door Yes
With sidewall Yes
Modular spacing 19 inch
Type of ventilation Active
Front door sort Single leaf perforated
Rear door sort Single leaf perforated
Product type Switching cabinet
Cabinet Width 600 mm
Depth 800 mm
Height 47U
Color RAL7011/7035 (gray/light gray)
Cabinet type Floor
