| Mounting method | Wall-/ceiling mounting |
| Colour | Grey |
| Width, mm | 70 |
| Depth, mm | 40 |
| Length, mm | 70 |
| Material | Plastic |
| Number of inlets | 10 |
| Cover attachment | Snapped on |
| Degree of protection (IP) | IP55 |
| Shape | Rectangular |
| For tube diameter | 20 mm |
| Type of housing feed-through | Seal membrane |
| Surface protection | Untreated |
| Model | Junction box |
| Halogen free | Yes |
| Equipped with | None |
| Color | gray |
| Height | 79 |
| Width | 79 |
| Depth | 48 mm |
| Temperature of mounting, °C | -5°С ... +60°С |
| Temperature of operation, °C | from -25°С to +60°С |
| Ingress Protection rating, IP | IP55 |
| 72 мм | 70 mm |
| 72 мм | 70 mm |
| 10 мм | 40 mm |
| Product type | Junction box with 8+2 cable inputs |
| ТУ 2248-012-47022248-2009 | Technical specifications 3464-028-47022248-2011 |
| 3 года | 3 years |
