| Mounting method | Wall-/ceiling mounting |
| Colour | Black |
| Width, mm | 80 |
| Halogen free | Yes |
| Depth, mm | 40 |
| Shape | Square |
| Surface protection | Untreated |
| Equipped with | None |
| Length, mm | 80 |
| Sealable | No |
| Material | Plastic |
| Cover attachment | Snapped on |
| Degree of protection (IP) | IP44 |
| Cover model | Mounting cover |
| Transparent cover | No |
| Mounting in the soil | No |
| Mounting under water | No |
| Number of inlets | 6 |
| Weatherproof | Yes |
| Type of housing feed-through | Seal membrane |
| Color | Black |
| Height | 84 mm |
| Width | 84 mm |
| -5°С ... +60°С | -5°С …+60°С |
| 72 мм | 80 mm |
| Degree of protection | IP44 |
| от -25°С до +60°С | -25°С …+60°С |
| 72 мм | 80mm |
| 10 мм | 40 mm |
| Depth | 45 mm |
| Product type | Junction box with cable inputs |
| ТУ 2248-012-47022248-2009 | Technical specifications 3464-028-47022248-2011 |
| 3 года | 3 years |
| Climate version | У2 |
