No name
Code: LBD23000106
No name
Code: LBD23000106
| Nominal cross-section of terminals | 4 mm2 |
| Terminal type | Screw |
| Quantity | 2 pc. x MVK.4(grey) +2 pc. х MVK.4(i) (blue) + 2 pc MVK.4T (yellow-green) |
| Type of a cable gland for | Armored cable |
| Series | КА |
| Installation side: A | 1 pc. x outer D: 9-17 mm / inner d: 5,8-12 mm |
| Installation side: B | 1 pc. x outer D: 9-17 mm / inner d: 5,8-12 mm |
| Installation side: C | 1 pc. x outer D: 9-17 mm / inner d: 5,8-12 mm |
| Installation side: D | 1 pc. x outer D: 9-17 mm / inner d: 5,8-12 mm |
| Material | Aluminium alloy |
| Product type | Explosion-proof box |
| Electrical equipment group | IIC hydrogen |
| Ex | d; tb |
