| Mounting method | Surface mounted (plaster) |
| Material | Aluminium |
| Explosion-tested version | Yes |
| Impact strength | IK07 |
| Cover attachment | Screwed |
| Degree of protection (IP) | IP66 |
| For Ex-zone gas | 1, 2 |
| For Ex-Zone dust | 21, 22 |
| Colour | Grey |
| Width, mm | 120 |
| Depth, mm | 90 |
| Length, mm | 120 |
| Number of inlets | 2 |
| Nominal cross-section of terminals mm2 | 2.5 |
| Terminal type | Screw |
| Quantity, pcs. | 6xCBC.2 |
| Type of a cable gland for: | Armored and Unarmored cable in a flexible conduit COSMEC |
| Series | KAEPM |
| Nominal diameter of the flexible conduit, mm | DN 20 |
| Installation side: A, mm | 1 X 5,8-12 |
| Installation side: C, mm | 1 X 5,8-12 |
| Material | Aluminium alloy |
| Product type | Explosion-proof box |
| Electrical equipment group | IIC hydrogen |
| Ex | e;t |
| Geometric dimensions, mm | 120x120x90 |
