| Nominal voltage, V | 230 |
| Method of operation | Rocker/button |
| Illumination | Possible to install an additional LED backlight |
| Rated current, A | 16 |
| Material quality | Thermoplastic |
| Number of rockers | 1 |
| Surface finishing | Glossy |
| Connection type | Screwed terminal |
| Number of modules (module system) | 2 |
| Colour | Black |
| Material | Plastic |
| Surface protection | Decor |
| Type of fastening | Screw mounting |
| Assembly arrangement | Basic element with central cover plate |
| Modular version | Yes |
| Wiring system | Intermediate switch |
| Push button switch | No |
| Suitable for degree of protection (IP) | IP20 |
| Width of device, mm | 44.9 |
| Height of device, mm | 44.9 |
| Depth of device, mm | 36.9 |
| Label space/information surface | No |
| Mounting method | Surface mounted (plaster) |
| Color | black square |
| Number of modules | 2 |
| Material | PVC |
| Product type | Intermediate switch |
| Type of installation | module element |
