| Surface protection | Untreated |
| Type of sealing | Sealing ring |
| Material quality | Polypropylene (PP) |
| Operational temperature, °C | -25...+60 |
| Material | Plastic |
| Pitch thread, mm | 1.954 |
| Flat cable coupling | No |
| For Ex-zone gas | None |
| Nominal thread size inch/gas pipe thread | 1/2 inch |
| For Ex-Zone dust | None |
| Colour | Grey |
| Model | Straight |
| Degree of protection (IP) | IP65 |
| Suitable for cable diameter, mm | 14...14 |
| Color | gray |
| -5°С ... +60°С | -5°С ... +60°С |
| Ingress Protection rating, IP | IP65 |
| от -25°С до +60°С | from -25°С to +60°С |
| Threading | 1/2" |
| Product type | Coupling spiralled sheath - box |
| ТУ 2248-012-47022248-2009 | Technical specifications 2247-023-47022248-2009 |
| 3 года | 3 years |
| 15 лет | 15 years |
