Residual-current circuit breaker (RCCB) with overcurrent protection YON MDR63-22C20-A (2p, 30mA)

Code: MDR63-22C20-A
Residual-current circuit breaker (RCCB) with overcurrent protection YON MDR63-22C20-A (2p, 30mA)
Residual-current circuit breaker (RCCB) with overcurrent protection YON MDR63-22C20-A (2p, 30mA)
Code: MDR63-22C20-A
  • To ask a question
  • Characteristics
  • Certificates
  • Promo
  • Viewed items
  • News
Rated current, A 20
Rated voltage, V 230
Release characteristic C
Rated fault current, A 30
Leakage current type A
Width in number of modular spacings 2
Degree of protection (IP) IP20
Number of protected poles 1
Concurrently switching N-neutral Yes
Rated short-circuit breaking capacity IEC 60947-2, kA 6
Number of poles (total) 2
