| Rated current, A | 80 |
| Rated voltage, V | 400 |
| Release characteristic | D |
| Degree of protection (IP) | IP20 |
| Concurrently switching N-neutral | No |
| Additional equipment possible | Yes |
| Number of poles (total) | 1 |
| Voltage type | AC |
| Connectable conductor cross section multi-wired, mm² | 25...25 |
| Ambient temperature during operating, °C | 30...30 |
| Connectable conductor cross section solid-core, mm² | 25...25 |
| Frequency, Hz | 50...50 |
| Rated short-circuit breaking capacity | 20 |
| Width in number of modular spacings | 2 |
| Built-in depth, mm | 69.9 |
| Suitable for flush-mounted installation | No |
