Junction box for solid walls, IP40, 297х152х70 mm

Code: 59367
Junction box for solid walls, IP40, 297х152х70 mm
  • To ask a question
Mounting method Facing brickwork
Colour Orange
Width, mm 297
Model Single
Halogen free No
Depth, mm 70
Construction type Cable junction box
Internal depth, mm 68.9
Length, mm 152
Sealable No
Material Plastic
Number of inlets 16
With screws No
Degree of protection (IP) IP40
Inlet from the rear No
Clamp position fixed No
Shape Rectangular
Cover Not transparent
Cover attachment Screwed
Number of modules 1
Temperature of mounting, °C -5°С ... +60°С
Ingress Protection rating, IP IP40
Temperature of operation, °C from -25°С to +60°С
