FUSEHOLDER TERMINAL BLOCK

Code: ZEFF400BL

Mounting method	DIN rail (top hat rail) 35 mm
Colour	Blue
Rated voltage, V	630
Length, mm	55.2
Operating temperature, °C	-60…130
Width/grid dimension, mm	6.2
Height at lowest possible mounting height, mm	67.1
Closing plate required	Yes
Type of fuse insert	G-fuse 5x20 mm
Type of fuse holder	Swivelling
Type of indication element for defect indication	LED
Supply voltage for defect-indication, V	630

Number of levels	1
Voltage type for defect indication	AC/DC
Connectable conductor cross section solid-core, mm²	6
Connectable conductor cross section fine-strand with cable end sleeve, mm²	4
Connectable conductor cross section fine-strand without cable end sleeve, mm²	4
Connectable conductor cross section multi-wired, mm²	4
Rated current In, A	6.3
Inflammability class of insulation material according to with UL94	V0
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Material insulation body	Thermoplastic
Connection position	Above
