FEED-THROUGH TERMINAL BLOCK

Code: ZEFC200BL

Mounting method	DIN rail (top hat rail) 35 mm
Colour	Blue
Number of poles	2
Length, mm	49.6
Operating temperature, °C	-60...130
Width/grid dimension, mm	5.2
Height at lowest possible mounting height, mm	39.2
PEN function possible	No
With integrated test socket	Yes
Number of levels	1
Number of clamp positions per level	2
Internally connected stages	Yes

Connectable conductor cross section solid-core, mm²	4...4
Connectable conductor cross section fine-strand with cable end sleeve, mm²	2.5...2.5
With shock protection	Yes
Rated current In, A	24
Explosion-tested version 'Ex e'	Yes
Inflammability class of insulation material according to with UL94	V0
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Material insulation body	Thermoplastic
Connection position	Above
Rated voltage, V	800
Closing plate required	Yes
