Double-wall tube HDPE flex. for cabling system ? 140 mm, SN 6, 450N, without pull, 50 m in coil, red color

Code: 120914
Double-wall tube HDPE flex. for cabling system ? 140 mm, SN 6, 450N, without pull, 50 m in coil, red color
Double-wall tube HDPE flex. for cabling system ? 140 mm, SN 6, 450N, without pull, 50 m in coil, red color
Colour Red
Model Pliable
Outer diameter, mm 140
Inner diameter, mm 120
Surface protection Untreated
Material quality Polyethylene
-- No
Shape Outer side ribbed, inner side plain
Color gray
Material Polyethylene
Length, mm 50000
Temperature of mounting, °C -25°С ... +90°С
Ingress Protection rating, IP IP44 (IP55, IP67)
Temperature of operation, °C from -55°С to +90°С
Cord for wires No
Radius of bending (min) , mm 1120
Certificates
Name Document
Double-wall tubes - Sanitary-epidemiological conclusion for double-wall tubes and double-wall flexible drainage pipe
PDF
1.15 MB
Double-wall tubes - Certificate of conformity to GOST R for double-wall flexible electrical tubes
PDF
14.38 MB
Exemption Letter for the pipes for electrical work
PDF
594.79 kB
Certificate of conformity to GOST R MEK 61386.24-2014 for the flexible dual wall corrugated pipes
PDF
448.57 kB
