Disconnector position indicator, with faston connector, body/cut-out ? 22/30, with round head, yellow, 24V
Code:
AP0F23DY24
Code:
AP0F23DY24
Removed from the product range
| Hole diameter, mm | 22 |
| Rated operating voltage Ue, V | 24...24 |
| Lamp type | LED |
| Degree of protection (IP) | IP54 |
| Voltage type | AC/DC |
| Type of lens | Flat |
| Type of electric connection | Flat plug-in connection |
| Colour front ring | Black |
| Material front ring | Plastic |
| Construction type lens | Round |
| Type of lamp socket | LED |
| Colour lens | Yellow |
| Number of indicator lights | 2 |
| With light source | Yes |
| Product type | Led Indicators |
