| Width, mm | 1860 |
| Height, mm | 1600 |
| Depth, mm | 1350 |
| Wiring system | DY |
| Degree of protection (IP) | IP31 |
| Built as energy saving transformer | No |
| Rated power, VA | 100 |
| Type of insulation material according to IEC 85 | F |
| Built as safety transformer | No |
| Built as isolating transformer | No |
| Complete device in housing | No |
| Secondary voltage 1, V | 400...400 |
| Primary voltage, kV | 10 |
| Secondary voltage, kV | 0.4 |
| Uk | 0.04 |
| Po | 430 W |
| Pk 120ºC | 1850 W |
| Sound preassure level | 48 dB |
| Option | antivibration mounts |
| 3 кВА (максимальный входной ток 13,6 А) | 100 kVA |
