No name
Code: TDA04ADYN1AI000
No name
Code: TDA04ADYN1AI000
| Width, mm | 1200 |
| Height, mm | 1550 |
| Depth, mm | 860 |
| Wiring system | DY |
| Degree of protection (IP) | IP00 |
| Built as energy saving transformer | No |
| Rated power, VA | 400 |
| Type of insulation material according to IEC 85 | F |
| Primary voltage, kV | 10 |
| Secondary voltage, kV | 0.4 |
| Uk | 0.06 |
| Po | 920 W |
| Pk 120ºC | 4800 W |
| Sound preassure level | 52 dB |
Certificates
| Name | Document |
|---|---|
