Floor cabinet Conchiglia 490x685x330мм

Code: 077702108
Colour Grey
Width, mm 685
Height, mm 490
Depth, mm 330
With mounting plate No
Number of doors 1
Number of locks 1
EMC-version No
With glazed door No
Floor mounting possible Yes
Material Plastic
Wall mounting possible No
Degree of protection (IP) IP65
Suitable for outdoor set-up Yes
Suitable for metrical mounting No
Mounting plate depth-adjustable No
Tackable Yes
With ventilation door No
Type of surface Untreated
With backside door No
Flush-mounted installation No
RAL-number 7035
Impact strength IK10
Material quality GRP
Wall build in No
Pitched roof No
Pole fastening No
Product type Conchiglia assembled enclosures
Mounting type Floor
Material Fiberglass
Door type Raised surface (antisticker)
Degree of protection IP65
Climatic version (according to GOST 15150-69) UHL1
Flammability ratings (according to UL94) V0
Impact protection ratings IK10
Delivery package Front door, rear wall, roof, base with solid panel
Modification possibility Enclosures can be connected in width, depth and height. The door hinge changes. Cut-outs on request.
Height 490 mm
Width 685 mm
Depth 330 mm
