4P+4P 25A CU - Straight element 3 meter - 3 plug-in
Code:
LTC25FSP43AA000
Code:
LTC25FSP43AA000
Removed from the product range
| Colour | Grey |
| Width, mm | 47 |
| Model | Double |
| Height, mm | 83.5 |
| Flexible | No |
| Number of conductors (without earthing) | 8 |
| Number of poles | 8 |
| Length, mm | 3000 |
| Degree of protection (IP) | IP55 |
| Rated voltage at AC 50 Hz, V | 400 |
| Number of tap-off units | 2 |
| Rated current at AC 50 Hz, A | 25 |
| Length busbar trunk, mm | 3000 |
| Series | Lightech |
| Color | gray |
| Modification | Double |
| Degree of protection | IP55 |
| Rated voltage | 400V |
| Phase conductor material | copper |
| In | 25A |
| Element type | Straight element |
| Busbar's number of conductors | 4P+4P |
| Phasing | L1+L2+L3+N/L1+L2+L3+N |
| Tap-off units quantity | 3+3 |
| Height | 60 mm |
| Width | 40 mm |
| Length | 3000 mm |
