4P 25A AL - Straight element 3 meter - 1 plug-in

4P 25A AL - Straight element 3 meter - 1 plug-in

Code: LTA25DSP42AA000

4P 25A AL - Straight element 3 meter - 1 plug-in

4P 25A AL - Straight element 3 meter - 1 plug-in

To ask a question

ETIM

Colour	Grey
Width, mm	47
Model	Single
Height, mm	83.5
Flexible	No
Number of conductors (without earthing)	4
Number of poles	4

Length, mm	3000
Degree of protection (IP)	IP55
Rated voltage at 50 Hz, V	400
Number of tap-off units	1
Rated current at AC 50 Hz, A	25
Length busbar trunk, m	3000

Drawings

Seria	Name	DWG	DWG (dynamic blocks)
Busbars	The busbars of the series "Hercules"	ZIP 6.21 MB
Busbars	The busbars of the series "Hercules"		ZIP 1.26 MB

Certificates

Name	Document
Certificate of compliance for lighting busbar_Hercules	PDF 614.31 kB
Certificate of compliance for lighting busbar_Hercules	PDF 610.38 kB
Certificate of compliance for lighting busbar_Hercules	PDF 619.21 kB
Certificate of conformity for busbars lighting for AC voltage up to 690 V (DKC Power Solutions S.r.l., type LT)	PDF 1.13 MB
The test report for compliance with TR ТС 004/2011 low-voltage complex devices "RAM power" for power distribution system for a rated current of 100 - 1600A	PDF 247.20 kB
Certificate of conformity to TR TS 004/2011 for tap-off units with phase selection	PDF 503.28 kB

Catalogs

Solutions for power distributing systems

Solutions for power distributing systems

Download

ZIP
