4P 25A AL - Straight element 3 meter - 2 plug-in
Code: LTA25DSP41AA000
4P 25A AL - Straight element 3 meter - 2 plug-in
Code: LTA25DSP41AA000
Removed from the product range
| Colour | Grey |
| Width, mm | 47 |
| Model | Single |
| Height, mm | 83.5 |
| Flexible | No |
| Number of conductors (without earthing) | 4 |
| Number of poles | 4 |
| Length, mm | 3000 |
| Degree of protection (IP) | IP55 |
| Rated voltage at AC 50 Hz, V | 400 |
| Number of tap-off units | 2 |
| Rated current at AC 50 Hz, A | 25 |
| Length busbar trunk, mm | 3000 |
