Outdoor wall-mounted conditioner 1500 W, 230 V, 1 ph, 950x400x237 mm

Code: R5KLM15021LO

Outdoor wall-mounted conditioner 1500 W, 230 V, 1 ph, 950x400x237 mm

Code: R5KLM15021LO
Width, mm 400
Model Air/air
Height, mm 950
Depth, mm 237
With temperature control Yes
Function master/slave Yes
Operating voltage at AC 50 Hz, V 230...230
Operating voltage at AC 60 Hz, V 230...230
Voltage type AC
With heating function Yes
Ambient temperature during operating, °C -60...55
Total cooling capacity according to EN 14511 at 35/35 °C, W 1500
Speed-regulated Yes
Product type Air conditioner
Class of cooling output, W 1500
Rated operating voltage V, ~, Hz 230 V, 1 p, 50/60 Hz
Version of cooler Outdoor
Mounting type Wall-mounted
External dimensions of cooler (W x H x D), mm 400 х 950 х 237
Temperature regulating range, ˚C +25…+40
Operating temperature range, ˚C -60…+55
Material Steel sheet
Degree of protection, internal circuit IP55
Degree of protection, external circuit IP34
Weight, kg 47
Refrigeration power DIN 3168 (L35/L35), W 1420
Refrigeration power DIN 3168 (L35/L50), W 1140
Rated power consumption (L35/L35), kW 0.66
Rated current, A 5.2
Protective device, A 8
Start-up current, A 24
Noise level, dB(A) 69
Coolant type R134a
