Busbar holder 30-120x5 3P 185mm
Code:
R5BBH185053P
Busbar holder 30-120x5 3P 185mm
Code:
R5BBH185053P
| Number of poles | 3 |
| Busbar distance, mm | 185 |
| Max. rated current, A | 2500 |
| Product type | Main bus system insulator |
| Q'ty of busbars for poles | 1 |
| Number of poles | 3 |
| Distance between poles | 185 mm |
| Length | 582 mm |
| Width | 29 mm |
| Height | 64,5 mm |
| Material | PA66, GV30, V0 |
| Bolt width | 30 - 120 mm |
| Bus thickness | 5 mm |
