Equipotential Busbar, 20 terminals, 680×40×4 mm, copper

Code: NE2020
Equipotential Busbar, 20 terminals, 680×40×4 mm, copper
Equipotential Busbar, 20 terminals, 680×40×4 mm, copper
Width, mm 40
Model Only clamp
Construction type Surface mounting fix
Length, mm 680
Insulator Yes
Surface of the clamp Untreated
Material of clamp Copper
Material of contact rail Stainless steel V2A
Number of connections round conductor total 20
Certificates
Name Document
Jupiter - Exemption letter for the lighting protection and grounding
PDF
693.33 kB
“Jupiter”_ Exemption Letter for accessories for an isolated current lead (cable)
PDF
541.89 kB
