Heat shrink flame retardant tube (roll) 38,1/19,1mm yellow

Code: 2NF201R381Y
Color gray
Material PVC
Temperature of mounting, °C > 90
Temperature of usage, °C -55... +135
Temperature of operation, °C 135
Diameter of surrounding (max), mm 38.1
Diameter of surrounding (min), mm 19.1
Colour Yellow
Model Thin-walled
Halogen free No
Wall thickness after shrinking, mm 1.02
Length, m 50
Material Polyolefin (PEX)
Operation temperature, °C -55…135
Inner diameter before heat-shrink, mm 38.1
Inner diameter after heat-shrink, mm 19.1
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 2:01
UL approval Yes
Type Heat-shrink
Seria Name Eplan
Quadro - Heat shrinkable tubes
