Heat shrink flame retardant tube (roll) 3,2/1,6mm black

Code: 2NF201R32
Color gray
Material PVC
Temperature of mounting, °C > 90
Temperature of usage, °C -55... +135
Temperature of operation, °C 135
Diameter of surrounding (max), mm 3.2
Diameter of surrounding (min), mm 1.6
Colour Black
Model Thin-walled
Halogen free No
Wall thickness after shrinking, mm 0.51
Length, m 300
Material Polyolefin (PEX)
Operation temperature, °C -55…135
Inner diameter before heat-shrink, mm 3.2
Inner diameter after heat-shrink, mm 1.6
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 2:01
UL approval Yes
Type Heat-shrink
