Heat shrink flame retardant tube (roll) 12,7/6,4mm clear

Code: 2NF201R127CL
Heat shrink flame retardant tube (roll) 12,7/6,4mm clear
Heat shrink flame retardant tube (roll) 12,7/6,4mm clear
Color gray
Material PVC
Temperature of mounting, °C > 90
Temperature of usage, °C -55... +135
Temperature of operation, °C 135
Diameter of surrounding (max), mm 12.7
Diameter of surrounding (min), mm 6.4
Colour Transparent
Model Thin-walled
Halogen free No
Wall thickness after shrinking, mm 0.64
Length, m 150
Material Polyolefin (PEX)
Operation temperature, °C -55…135
Inner diameter before heat-shrink, mm 12.7
Inner diameter after heat-shrink, mm 6.4
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 2:01
UL approval Yes
Type Heat-shrink
Drawings
Seria Name Eplan
Quadro - Heat shrinkable tubes
The System "Quadro"
RAR
27.23 MB
Certificates
Name Document
Quadro_ Exemption Letter for shrink tubes_DIN-rail, braid, frames and frames for EUI, drawing, accessories_1
PDF
1.30 MB
