Heat shrink flame retardant tube 38,1/19,1 mm blue
Code: 2NS201381B
Heat shrink flame retardant tube 38,1/19,1 mm blue
Code: 2NS201381B
| Colour | Blue |
| Model | Thin-walled |
| Halogen free | No |
| Wall thickness after shrinking, mm | 1.02 |
| Length, m | 1 |
| Material | Polyolefin (PO-X) |
| Operating temperature, °C | -55…135 |
| Inner diameter before heat-shrink, mm | 38.1 |
| Inner diameter after heat-shrink, mm | 19.1 |
| Printable | No |
| With inner glue | No |
| Nominal diameter inch | Other |
| Shrink rate | 2:1 |
| UL approval | Yes |
| Type | Heat-shrink |
| Delivery form | 1 meter pieces |
| Product type | Heat shrinkable tubes |
