Heat shrink tube 3,2/1,6mm blue

Code: 2NA20132B
Heat shrink tube 3,2/1,6mm blue
Heat shrink tube 3,2/1,6mm blue
Color gray
Material PVC
Temperature of mounting, °C > 90
Temperature of usage, °C -55... +105
Temperature of operation, °C 105
Diameter of surrounding (max), mm 3.2
Diameter of surrounding (min), mm 1.6
Colour Blue
Model Thin-walled
Halogen free Yes
Wall thickness after shrinking, mm 0.51
Length, m 1
Material Polyolefin (PEX)
Operation temperature, °C -30…105
Inner diameter before heat-shrink, mm 3.2
Inner diameter after heat-shrink, mm 1.6
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 2:01
UL approval Yes
Type Heat-shrink
Drawings
Seria Name Eplan
Quadro - Heat shrinkable tubes
The System "Quadro"
RAR
27.23 MB
Certificates
Name Document
Quadro_ Exemption Letter for shrink tubes_DIN-rail, braid, frames and frames for EUI, drawing, accessories_1
PDF
1.30 MB
