Heat shrink flame retardant tube 12/4mm black 3:1

Code: 2NF301120
Color gray
Material PVC
Temperature of mounting, °C > 90
Temperature of usage, °C -55... +135
Temperature of operation, °C 135
Diameter of surrounding (max), mm 12
Diameter of surrounding (min), mm 4
Colour Black
Model Thin-walled
Halogen free No
Wall thickness after shrinking, mm 0.70
Length, m 1
Material Polyolefin (PEX)
Operation temperature, °C -55…135
Inner diameter before heat-shrink, mm 12
Inner diameter after heat-shrink, mm 4
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 3:01
UL approval Yes
Type Heat-shrink
Drawings
Seria Name Eplan
Quadro - Heat shrinkable tubes
