Heat shrink tube 50,8/25,4mm blue

Code: 2NA201508B
Heat shrink tube 50,8/25,4mm blue
Heat shrink tube 50,8/25,4mm blue
Colour Blue
Model Thin-walled
Halogen free Yes
Wall thickness after shrinking, mm 1.10
Length, m 1
Material Polyolefin (PEX)
Operation temperature, °C -30…105
Inner diameter before heat-shrink, mm 50.8
Inner diameter after heat-shrink, mm 25.4
Printable No
With inner glue No
Nominal diameter inch Other
Shrink rate 2:01
UL approval Yes
Type Heat-shrink
Delivery form 1 meter pieces
Product type Heat shrinkable tubes
Drawings
Seria Name Eplan
Quadro - marking systems
The System "Quadro"
RAR
27.23 MB
Certificates
Name Document
Quadro_ Exemption Letter for shrink tubes_DIN-rail, braid, frames and frames for EUI, drawing, accessories_1
PDF
1.30 MB
