Heat shrink medium wall tube 115/35mm

Code: 2CRM115
Heat shrink medium wall tube 115/35mm
Heat shrink medium wall tube 115/35mm
Color gray
Material PVC
Temperature of mounting, °C > 110
Temperature of operation, °C -40... +120
Temperature of operation, °C 120
Diameter of surrounding (max), mm 115
Diameter of surrounding (min), mm 35
Colour Black
Model Medium-walled
Halogen free Yes
Wall thickness after shrinking, mm 3.10
Length, m 1
Material Polyolefin (PEX)
Operation temperature, °C -40…120
Inner diameter before heat-shrink, mm 115
Inner diameter after heat-shrink, mm 35
Printable Yes
With inner glue No
Nominal diameter inch Other
Shrink rate 4:01
UL approval No
Type Heat-shrink
Drawings
Seria Name Eplan
Quadro - Heat shrinkable tubes
The System "Quadro"
RAR
27.23 MB
Certificates
Name Document
Quadro_ Exemption Letter for shrink tubes_DIN-rail, braid, frames and frames for EUI, drawing, accessories_1
PDF
1.30 MB
Exemption Letter for on fasteners "F5 Combitech"
PDF
4.01 MB
Russian Maritime Register of Shipping for wire cable trays F5 Combitech_1
PDF
700.24 kB
