Horizontal ladder bend 90 degrees 100x600, R660 ZL

Horizontal ladder bend 90 degrees 100x600, R660 ZL

Code: ULD616ZL

Horizontal ladder bend 90 degrees 100x600, R660 ZL

Horizontal ladder bend 90 degrees 100x600, R660 ZL

To ask a question

Material	PVC
Width, mm	1460
Length, mm	1460

Climate version	U1, HL1, UHL1, UHL5, OM1
Radius of bending, mm	600
Thickness of side walls, mm	1.5

Colour	Light grey
Model	Without connector
Surface protection	Continuously galvanized zinc-aluminium
Deflection (angle)	90°
Type of rung	Perforated profile
Side wall perforation	Yes
Material quality	Other
Material	Steel

Inner radius, mm	600
Cable ladder width, mm	600
Cable ladder height, mm	100
Change of direction	Horizontal
Stainless steel, pickled	No
Wide span model	Yes
Type of side joist	Profile (open)
Suitable for circuit integrity	No
