Horizontal ladder bend 45 degrees 100x1000, R660, hot-dip galvanized

Code: ULC610HDZ
Horizontal ladder bend 45 degrees 100x1000, R660, hot-dip galvanized
Horizontal ladder bend 45 degrees 100x1000, R660, hot-dip galvanized
Material PVC
Height, mm 100
Width, mm 1293
Length, mm 1417
Climate version U1, HL1, UHL1, UHL5, OM1
Radius of bending, mm 600
Thickness of side walls, mm 1.5
Colour Light grey
Model Included connector
Surface protection Hot-dip galvanized
Deflection (angle) 45°
Type of rung Perforated profile
Side wall perforation Yes
Material quality Other
Material Steel
Inner radius, mm 600
Cable ladder width, mm 1000
Cable ladder height, mm 100
Change of direction Horizontal
Stainless steel, pickled No
Wide span model Yes
Type of side joist Profile (open)
Suitable for circuit integrity No
