| Model | Impact |
| Surface protection | Hot-dip galvanized |
| Min. drill hole depth, mm | 67 |
| Material sleeve | Steel |
| Length, mm | 90 |
| Thread size (metric) | 10 |
| Drill hole diameter, mm | 15 |
| Self boring | Yes |
| App. load pull zone, kN | 20.6 |
| Fastening provision | Nut |
| Material | Steel |
| Threading | M10 |
| Length | 90 mm |
| Type | Anchor with stud |
