Cable socket CS IP44 16A 2P 50V

Code: CS024-016-05
Code: CS024-016-05
  • To ask a question
Angle of plug Straight
Clock hour position, h 6
Cable entry Swivel
Number of poles 2
Material Plastic
IEC-amperage, A 16
Connection system Screwed terminal
Degree of protection (IP) IP44
Voltage according to EN 60309-2 40-50 V (50+60 Hz) white
GWFI +850 °С
Q'ty of poles 2P
Temperature of operation +40 °С
Material of case Ployamide
Voltage 50V
Degree of protection IP44
-5°С ... +60°С -25 °С...+40 °С
Temperature of dinamic operation -25 °С...+40 °С
Temperature of static operation -40 °С...+40 °С
Product type Cable socket
Current 16A
Color White
Honest SIGN system. Commodity group Radio‑electronic products
Russian Classification of Products by Economic Activities (OKPD 2) 27.33.13.110
Commodity Nomenclature of Foreign Economic Activity 8536699008
Clock position 12 h
