Power terminals screw bimetallic 240mm²

Code: 2P12B

Suitable for Al/St-cables	Yes
Cross section form	Round stranded/sector stranded
St nominal cross section, mm²	240

Insulation

Not isolated

Flange shape

Ring shape
