No name

Code: DIS2471697
  • To ask a question
Width, mm 70
Height, mm 87
Depth, mm 110
Lockable No
With hinged lid No
With socket outlet No
Number of phases 3
With child-protection No
Frequency, Hz 50
Cable entry Gland nut
Extension possible No
With transparent cover No
Switch-off function No
Fault current protection No
Number of poles 5
Contact less detection of the sense of rotation No
Material Plastic
IEC-amperage, A 16
For heavy conditions (in accordance with VDE) No
Phase inverter No
Empty locations on mounting rail No
Number of height units 1
With earth leakage switch No
Degree of protection (IP) IP67
Total number of groups 1
Clock hour position, h 6
Identification colour Red
Voltage acc. EN 60309-2 400 V (50+60 Hz) red
Drill hole distance vertical, mm 70
Drill hole distance horizontal, mm 56
Width of device, mm 88
Height of device, mm 144
Depth of device, mm 101
Angle of plug Angled
Connection system Screwed terminal
Product type Flush-mounting plug
Voltage 400V
