Terminal blocks polyamide 6.6, 3р, 110 °С, 450V, 32A, 4mm² (р)
Code: 43303NYR
Terminal blocks polyamide 6.6, 3р, 110 °С, 450V, 32A, 4mm² (р)
Code: 43303NYR
Mounting method | Direct mounting |
Colour | White |
Rated voltage, V | 450 |
Number of poles | 3 |
Length, mm | 23.65 |
Operating temperature, °C | -40...110 |
Number of clamp positions per pole | 2 |
Width/grid dimension, mm | 20.2 |
Closing plate required | No |
Transparent | No |
Connectable conductor cross section multi-wired, mm² | 6 |
Rated current In, A | 32 |
Explosion-tested version 'Ex e' | No |
Inflammability class of insulation material according to with UL94 | Other |
Type of electrical connection 1 | Screw connection |
Type of electrical connection 2 | Screw connection |
Material insulation body | Polyamide (PA) |
Connection position | Sideways |
Product type | Screw terminal blocks |
Drawings
Seria | Name | Eplan |
---|---|---|
Terminal blocks - "Quadro"
|
