Height, mm 51.9
Width, mm 105.8
Depth, mm 31.2
Mounting method Other
Colour Other
Nominal rated voltage, V 750
Number of poles 1
Length, mm 105,8
Operation temperature, °C -5…85
Number of clamp positions per pole 2
Width/grid dimension, mm 31,2
Closing plate required No
Transparent No
Connectable conductor cross section multi-wired, mm² 25...70
Explosion-tested version 'Ex e' No
Inflammability class of insulation material acc. with UL94 Other
Type of electrical connection 1 Spring clamp connection
Type of electrical connection 2 Spring clamp connection
Material insulation body Polycarbonate
Connection position Above
Drawings
Seria Name Eplan
Quadro - terminal blocks
