Butt connectors copper tinned 1,5-2,5mm²

Code: 2B20P

To ask a question

Color	gray
Material	Brass

Width, mm	5.5
Length, mm	23

Surface protection	Tinned
Material	Copper
Model	Standard version
Type of connection	Percussion connector
Insulation	PVC
Oil stop/centre bar	No
For pull protected connections	No
Colour insulation	Blue
Number of branches	1

Nominal cross section, mm2	1.5…2.5
Suitable for fine strand conductors	Yes
Suitable for flat conductors	No
Suitable for high temperatures (to 650	No
Suitable for insulated varnish	No
Suitable for solid cores	Yes
Useful for stranded conductors	Yes
Suitable for round conductors	Yes
Sleeve form	Long
